Microscope Variable Focus Lens

DOM 3000E ergonomic surgical microscope

Ergonomic binocular tube (210˚ movement) Semorr knows that every surgeon's comfortable working positions are different. To relieve shoulder, neck and lower back muscle fatigue during prolonged surgery and keep surgeons safe from occupational diseases.

Flexible balance system. The precise mechanical balancing structure ensures that the swing arm rotates flexibly and the microscope arm moves up and down smoothly. The load weight is pre-calculated to maintain the smooth movement and precise position of the DOM300 when accessories are added.

Features of the DOM 3000E Microscope:

• 360° rotating handle: Easy positioning at any angle you prefer.
• Pendulum structure: The binoculars will remain at the same height as the floor during the rotational movement. This design allows the surgeon to keep the head and back in a comfortable position and alleviate the fatigue of long-duration surgery.
• High transparency optics: Optical glass made in Germany, superior quality, multi-coated, high resolution, high definition, high depth of view and wide field of view.
• Integrated yellow filter: Attach the yellow filter to prevent premature curing of the composite.
• Stable and lifelong LED lighting: Patented LED system, save energy, no heat, no noise. It makes the simulation of natural light, which makes the image clear, sharp and real. The whole field of view is evenly illuminated.
• Precise Zoom System: Continuous zoom allows operators to magnify and focus on an object with multiple magnifications without interruption.
• Ergonomic binocular tube: Variable angle (0 - 210º) helps prevent muscle fatigue in the shoulders, neck and lower back during prolonged surgeries.
• Beam splitter 50:50, beam splitter that allows the adaptation of a camera to capture moments of the intervention.

Technical Specifications of the DOM 3000E Microscope:

Specifications of the Microscope System:

• Eyepieces: 12.5X / 18B (18 mm aperture)
• Binoculars: tiltable 0 - 210 °
• Adjustable range: 50 - 75 mm
• Diopter range: ± 6
• Magnification: 3.6X - 23X
• Objective lens: f = 250 mm

Illumination System Specifications:

• Light source: LED module, variable brightness, more than 60000 hours life time
• Minimum illumination intensity: > 80000 Lux
• Diameter of illumination point: 85 mm
• Filter: orange and green
• Colour temperature: 6500 k, close to daylight

Bracket Specifications:

• Stable and patented floor stand
• Swing arm: rotation radius 460 mm, 360° rotation
• Microscope arm: rotation radius 700 mm, rotation ± 160 °, up/down ± 315 mm
• Longest arm reach: 1390 mm
• Base dimension: 516 mm x 516 mm
• Weight: 115 kg

Electrical System Specifications:

• Input voltage: AC100-240V; 50/60 Hz
• Maximum power consumption of the light source: 20 VA
• Total power consumption: 68 VA
• Fuse: 220V T1.0AL; 250V / 110V T2.0AL 125V

DOM 3000D-4K Microscope Contents:

• 1 Microscope Microscope DOM 3000E
• 1 Varioscope 200-400 mm
• 1 Beam Splitter
• 1 movable stand
